| Features
|
|
| Measuring
Travel - 8” (200mm) (X), 6” (150mm) (Y), 8” (200mm)
Focus. Optional 12” (300mm) (X). Quick release with
fine adjust on X axis. Optional joystick control with
fine adjust |
 |
| Resolution
- .00005" (.001mm) |
|
| Top
Plate - 12” x 14” (300mm x 350mm), black anodized with
standard clamping slot. Optional 12” x 18” (300mm x
450mm) |
|
| Weight
Capacity - 25 lbs. (10kg) |
|
| Illumination
- Remote Light Source for Profile & Fiberoptic Ring-light
Surface Illumination (100 watt Tungsten Halogen lamps)
|
|
| Video
System - High Res. ½” Black & White Camera, 13”
Black & White Monitor. Optional High Res. ½” Color
Camera, 14” Color Monitor. |
|
| Digital
Readouts - Choice of several DRO options including all
QuadraChek geometric digital readouts. Optional Video
Edge Detection and CNC control. |
|
| Optics
- 6:1 Zoom lens (Approximate magnification 30-180X)
Optional 2X and .5X multipliers |
|
| Digital
Crosshair Generator - Single or dual crosshair with
mouse controlled position and auto-edge detection. Mouse
included |
|
| Heavy
Duty Dust Cover |
|
