    8600 Series
    The 8600 Series video inspection system is the perfect alternative and compliment to the optical comparator. Precision, zoom optics combined with a high resolution camera and monitor provide a superior image for inspection. A digital crosshair generator, 4" x 8" travel measuring stage and choice of 4 available digital readout systems complete the package. The 8600 features S-T's exclusive gothic arch bearing ways which provide the best accuracy and life.



    Features
    Measuring Travel - 8" (200mm) (X) . 4" (100mm) (Y) . 5" (125mm) Focus (Optional 12" (300mm) (X) Quick Release with fine adjust on X axis (Optional Joystick control with fine adjust knobs)
    Resolution - .00005" (.001mm)
    Top Plate - 10" x 14" (250mm x 350mm), black anodized with standard clamping slot (Optional 10" x 18" (250mm x 450mm)
    Weight Capacity - 25 lbs. (10kg)
    Illumination - Profile and Fiberoptic Ringlight Surface (Tungsten Halogen)
    Monitor - 13" Black and White (Optional Color Camera/Monitor)
    Digital Readouts - Choice of several DRO options including all QuadraChek geometric digital readouts. (Optional Video Edge Detection and CNC control)
    Optics - 6:1 Zoom lens (Approximate magnification 30X-180X) (Optional 2X and .5X multipliers
    Digital Crosshair Generator
    Optional Laser Pointer
    Heavy Duty Dust Cover
